MASTECH MS8239C Auto Range Digital Multimeter Temperature Frequency

Attention: Mamnoon do not provide technical support for this Product. User must know how to use it. If not, Please think twice before order.
✪ Please check and confirm the package content and the price before buying. After used no return.
✪ If you want to buy any products, you can order online for home delivery or visit our shop.
✪ Please feel free to Contact Us if you need any further information.

Description :

MASTECH MS8239C Digital Auto Range Multimeter AC DC Voltage Current Capacitance Frequency Temperature Tester

The Mastech MS8239C is a budget multimeter, it can test AC/DC voltage, current, resistance, capacitance, frequency, duty cycle, temperature, diode, continuity check etc.
Besides, the portable hand-hold appearance design , high qaulity, accuracy and simple visible operation interface will make it very popular in electrical testing field.

Specifications :

Environmental Conditions : 600V CAT III, Pollution Degree : II. Altitude <2000 m
Working temperature and humidity : 0 – 40 ° C (<80% RH, <10° C is not considered)
Storage temperature and humidity : -10 – 60 ° C (<70% RH, battery removed)
Temperature Coefficient : ±0.1 Accuracy /° C (<18 ° C or > 28 ° C)
Allowed maximum voltage between the measuring terminal and the earth : 600V DC or 600V AC RMS
Fuse protection :
mA file: Fuse F400mA / 500V
10A file: Fuse F10A / 500V
Sampling rate : about 3 times / sec
Display : 3 3 / 4 LCD display
Over-range indication : LCD will show “OL”
Low battery indication : When the battery voltage is lower than the normal operating voltage , it will be displayed on the LCD screen
input polarity indication : Auto shows ” – ” sign

DC voltage : 400mV / 4V / 40V / 400V / 600V ± (0.5% +3)
AC voltage : 4V / 40V / 400V / 600V ± (1.2% +5)
DC current : 400uA / 4000uA / 40mA / 400mA ± (1.0% +5), 10A ± (2.0% +10)
AC current : 400uA / 4000uA / 40mA / 400mA ± (1.2% +5), 10A ± (2.5% +10)
Resistance : 200Ω / 2KΩ / 20KΩ / 200KΩ / 2MΩ ± (0.8% +5)
Capacitance : 5nF / 50nF / 500nF / 5uF / 50uF / 100uF ± (3.0% +5)
Frequency : 9.999HZ – 9.999MHz ± (1.5% +5)
Duty cycle : 0.1% – 99.9% ± (3.0% +5)
Temperature (° C) : -20 ° C – 1000 ° C ± (3.0% +3)
Temperature (° F) : -4 ° F – 1832 ° F ± (3.0% +3)
Diode and continuity.
Power supply : 2 x 1.5V AAA (Not included)
Size : 150mm x 74mm x 41mm
Weight : 202g
Safety Level : CE CAT.III 600V RoHS

► 1 Pcs MASTECH MS8239C Auto Range Digital Multimeter
► 1 Pair Test Lead
► 1 Pair Tempereture Probe
► 1 Pcs English Manual
